Digital Signage: how does this all work and what do I need?

1. Digital Signage Display  – First you need a commercial grade ViewTV (or your own) LED/LCD display. This is used to display your content.

2. Digital Signage PC  (ViewTV PC with “Playlist” software)ViewTV Playlist Digital Signage Software manages all your content to your Displays.

3. Content Hosting  – Content is hosted by us (on our Internet based servers) or by you. Update your Displays via a web browser online account or locally

The Benefits of Digital Content

1: Reduce Ongoing Costs
After your initial investment (like all investments) Digital Signage will reduce your ongoing printing and distribution costs of static signage and eventually pay for itself
over and over again.



2: Digital Technology
Installing a Digital Display gives you far more versatility than a static print. Display Video content, Live TV (Or any HD input), Scrolling Text Messages, RSS Feeds, Real Time
Weather and Time/Date information. Even integrate with Databases (Exchange Rates/Flight Times etc…), Websites, Twitter, Facebook or 3 Party Content Providers.



3: Remote Content Management

Remotely time schedule and manage your display or entire network of displays from anywhere in the world via a web browser user account. Instantly update content,

influence purchase decisions and effectively inform or engage with your target audience using ViewTV Playlist Digital Signage Software.

Portrait

Landscape

● Daylight readable commercial grade LCD display
● Fully enclosed powder coated steel casing
● Industrial standard power supply
● Real time connectivity and content management
● Built in speakers & line level audio input / output
● Programmable 24 Hr On / Off timer
● Plug and Play setup

Special Features

rss

Live RSS Feed
Automatically download and display live RSS feeds from any URL or FTP server directly to one of five available display zones

wifi

Wireless Update
Connect and upload content to our wireless capable Display Screens from anywhere in the world over the Internet or Internal Network

usb

USB Update
Upload content on site via a USB Drive. Our Plug and Play automated USB connection will automatically upload and update all content

Multi Zone Layout

A layout is the arrangement of rectangular zones to be shown on the display screen. Each zone has a playlist and each playlist contains the media that will play in that zone. Zones can be individually stretched to any size and then positioned anywhere on the display.

zones



 Display up to 5 zones

 Any size

 Any position







Control Software

● Windows based (XP Sp2 and up)
● User rights management
● Daily log content update status
● Network data encryption
● Group upload feature – Supports over 200 displays
● High speed FTP server
● 10/100 Ethernet, WiFi
● Supports BT downloading
● Terminal data encryption

Applications

Integrating our trademarked HD Firmware and a solid state SATA hard drive into the LCD panel, we offer both stand alone portable digital signage platforms and fixed permanently installed displays requiring NO 3rd party media players, DVD players or external devices.

ftp



apps

● Retailers
● Real Estate Agencies
● Airports
● Banks
● Hotels
● Malls
● Exhibitions
● Field days
● Showrooms
● Trade Shows
● Expos
● Corporate Events



Specifications

SIZE 32″ 42″
Dimensions 770mm x 460mm x 100mm 1000mm x 600mm x 105mm
Weight 18kgs 27kgs
Display Resolution 1366 x 768 1920 x 1080
Brightness 450 Nits 500 Nits
Contrast Ratio 1500:1 1500:1
Viewing Angle 176 / 176 178 / 178
Response Time 6ms 6ms
Aspect Ratio 16:10 16:10
Built In Speakers 2 x 10W 2 x 10W
Audio Inputs / Outputs 3.5mm Jack 3.5mm Jack
Input Resolution 720p, 1080i 720p, 1080p
Video Inputs VGA, Y Pb Pr, HDMI VGA, Y Pb Pr, HDMI
RF In Optional Optional
Voltage Frequency 240V / 60Hz 240V / 60Hz
Supported File Types: * Image Jpeg, Bitmap, PNG, GIF Jpeg, Bitmap, PNG, GIF
  * Video Mpeg4, AVI, WMV, H.264, MOV Mpeg4, AVI, WMV, H.264, MOV
  * Audio Mp3, WMA, WAV, AC3 Mp3, WMA, WAV, AC3
  * Text / RSS Feed Doc, Txt Doc, Txt
* Flash / Power point and all other video formats can easily be converted to a supported file type



Portable LCD Digital Advertising Players

portableOur Full HD 1080p Portable LCD Signage Displays are perfect for any event requiring a professional reliable visual display solution (with or without audio)

Our “all in one” display has a built in Hard Drive and requires NO 3rd Party External Devices
E.g. DVD Player, Laptop, Media Player or Protruding Cables

Hire:
1. Simply email us your presentation, event time and destination
2. We will have your display delivered, setup and running before your event begins

● Plays ALL Video, Picture and Audio formats
● Daylight readable commercial grade LCD display
● Fully enclosed powder coated steel casing
● Built in speakers & line level audio input / output
● Programmable 24 Hr On / Off timer
● Plug and Play setup

usb

USB Update
Upload content on site via a USB Drive. Our Plug and Play automated USB connection will automatically upload and update all content
